Myon I

Name: Myon I
SKU: Myon I

搭载骁龙™ 410E 的微型中央处理器模块

Development

Sampling

Production

Available in Industrial Temperature Range

Data Sheet

联系我们

CPU

Qualcomm® Snapdragon™ 410E Low Power Processor, 64bit, Cortex A53, QuadCore up to 1.2GHz

Graphics

OpenGL ES 3.0, OpenCL / DirectX 12 graphics acceleration support for Windows 10 IoT Core

Connectivity

Onboard WLAN 802.11 b/g/n 2.4 GHz, Bluetooth 4.1, USB 2.0, LVDS, MIPI Display and Kamera

Memory

EMCP incl. LPDDR3 -1066 (533MHz) up to 2 GByte and eMMC up to 16 Gbyte

Product details

Description

Industrial SOM solution with Qualcomm® Snapdragon™ 410E QuadCore processor, which enables high operating frequencies with low power consumption.
Processor

Qualcomm® Snapdragon™ 410E QuadCore ARM Cortex A53, up to 1.2GHz (APQ8016E), ARM Cortex M3
Memory

Myon II: Soldered down LPDDR4-3200 memory, 32-bit interface, up to 8GB
Myon II Nano: Soldered down LPDDR4-3200 memory up to 4 GB, 16-bit interface
Graphics

Qualcomm® AdrenoTM 306 400MHz GPU
OpenGL ES 3.0, OpenCL, DirectX
Video Interfaces

LVDS or MIPI Display (4 channel)
Video Resolution

LVDS, MIPI: 1080p @30
Mass Storage

onboard 8 Bit wide eMMC
2x SDIO interface (e.g. for external SD cards)
Networking

Onboard WLAN 802.11 b/g/n 2.4 GHz, Bluetooth 4.1 (On-board antennas or UFL connectors)
Ethernet via USB possible
USB

USB 2.0 OTG
PCI-e

PCIe (for Myon II)
Audio

Audio Codec: Stereo Headphone output, Mono Speaker 8Ω, 3 Microphone inputs
Other Interfaces

SD/SDIO Card, MIPI Camera (2ch and 4Ch)
8 Ports configurable for different interfaces:
GPIO, UART, SPI, I2C, I2S
Power Supply

LiPo 3 - 4.5V / typ. 3.3V / charger 5V
Operating System

Windows 10 IoT Core, Linux, Android
Operating Temperature

-25 ÷ 85°C
Dimensions

48 x 32 x 4.2 mm without antennas / 58 x 32 x 4.2 mm with antennas
