FLEXY VISION 21.5

Intel® Celeron® J3455, Quad Core @1.5GHz (Burst 2.3GHz), 2MB L2Cache, 10W TDP

Intel® Atom™ x5-E3940 Quad Core @1.6 GHz (Burst 1.8GHz), 2MB L2 Cache, 9.5W TDP

Intel® Celeron® N3350 Dual Core @1.1GHz (Burst 2.4GHz), 2MB L2 Cache, 6W TDP

Dual/ Quad Channel soldered down LPDDR4 memory, up to 8GB

Integrated Intel® HD Graphics 500 series controller, with up to 18 Execution Units

4K HW decoding and encoding of HEVC(H.265), H.264, VP8, VP9, MVC

Two DP++ 1.2 interfaces on miniDP connectors

1920x1080

M.2 2260 SATA SSD Module, up to 512GB

Dual Gigabit Ethernet RJ45 connector with Gigabit Ethernet i210 controllers

M.2 WLAN Connectivity Slot for accessory WiFi/BT module

2 x USB 3.0 Host ports on USB 3.0 Type-A sockets

Power ON Button with integrated LED

TPM 2.0 on-board

2x SMA connectors for external WiFi antennas

+18VDC ÷ +32 VDC recommended

+15VDC ÷ +36 VDC absolute

RTC battery

Microsoft® Windows 10 Enterprise (64 bit)

Microsoft® Windows 10 IoT Core

Yocto (64 bit)

Linux

0°C ÷ +50°C *

*Measured at any point of the heatspreader/heatsink during any and all times (including start-up). Actual temperature will widely depend on application, enclosure and/or environment. Upon customer to consider specific cooling solutions for the final system to keep the heatspreader temperature in the range indicated.
